Amplifiers
Maintaining a strong and reliable communication system is essential, especially for military and airborne applications. Mnemonics Inc. offers High Power Amplifiers (HPA) designed to enhance wireless communication systems. These advanced amplifiers are engineered for performance and durability, ensuring consistent and effective communication in demanding environments. To learn more about how Mnemonics Inc.’s High Power Amplifiers can support your communication needs, contact us for detailed information on their features and benefits.
Mnemonics 200 Watt Power Amplifier
Part# 980-1249 | Rack Mounted Part# 990-1144
Featuring cutting-edge technology and robust design, the Mnemonics 200-Watt Power Amplifier is your go-to solution for all your amplification needs.
Are you in need of a powerful amplifier that ensures your mission-critical operations are consistently reliable? Get peace of mind knowing that you’re investing in the best technology at an affordable price: Trust Mnemonics, Inc. for quality manufacturing and development.
Key Features
- UHF Military SATCOM: Enjoy reliable and secure communication with our UHF Military SATCOM compatible amplifier. Perfect for military operations or any situation where secure communications are paramount.
- Wide Range of Waveforms: Our amplifier supports FM, FSK PSK CPM, TDMA/DAMA, MUOS, and WCDMA waveforms, providing versatility and adaptability to a variety of communication scenarios.
- Continuous and Pulse Transmit: Designed for both continuous and pulse transmission, it ensures smooth and consistent signal output.
- Health & Status: Comes equipped with a health and status monitoring feature, allowing you to keep track of the device’s operational status and health in real time.
- Low Power Usage – High Efficiency: Despite its powerful performance, the amplifier maintains high efficiency with low power usage, making it a cost-effective choice.
- Lowest Cost: Priced competitively, our amplifier offers high-end features at an affordable cost.
- Keyed 630 Watts – Max: Achieve maximum output of 630 watts when keyed, ensuring optimal signal amplification.
- Unkeyed LL4 Watts – Max: Even when not keyed, the amplifier can output a maximum of LL4 watts.
Benefits
- Versatility: Supports various waveforms, perfect for diverse operational requirements.
- Performance: Continuous and pulse transmission ensures optimal performance.
- Monitoring: Real-time health & status updates allow for effective preventive maintenance and troubleshooting.
- Efficiency: Low power usage without compromising on performance.
- Affordability: High-end features at a competitive price.
- Power: High maximum output, whether keyed or unkeyed, ensuring robust signal amplification.
Download the 200W HPA Datasheet here to learn more.
Experience Unmatched Performance with Mnemonics 200 Watt Power Amplifier
The Mnemonics 200-Watt Power Amplifier is not just an ordinary amplifier; it is a powerhouse of features and benefits that are designed to exceed your expectations.
Expect Powerful Performance
Our amplifier promises high performance, thanks to its maximum output of 630 watts when keyed and LL4 watts when unkeyed. This ensures powerful signal amplification, regardless of the operational mode, making it suitable for a wide range of applications. Whether you’re running a military operation or hosting a large-scale event, you can rely on our amplifier’s robust performance.
Expect Versatility
With support for a variety of waveforms such as FM, FSK PSK CPM, TDMA/DAMA, MUOS, and WCDMA, this amplifier is not only versatile but also adaptable. It can seamlessly fit into different communication scenarios, making it an ideal choice for dynamic operations. The continuous and pulse transmit feature further augments its versatility, ensuring smooth and consistent signal output in varying conditions.
Expect Operational Efficiency
In an era where energy efficiency is crucial, our amplifier stands out with its low power usage. Despite its high performance, it maintains an impressive level of efficiency, thus contributing to cost savings in the long run. This makes it an ideal choice for operations that demand high performance without compromising on energy efficiency.
Expect Real-Time Monitoring
Our amplifier’s health & status feature provides real-time insights into the device’s operational status and health. This proactive monitoring allows you to address potential issues before they escalate, thereby ensuring uninterrupted service. This feature not only enhances the operational reliability but also extends the lifespan of the amplifier.
Expect Affordability
We believe that high-end features should not come at a high-end price. That’s why we’ve priced our amplifier competitively, ensuring you get the best value for your investment. With the Mnemonics 200-Watt Power Amplifier, you can experience top-tier features without breaking the bank.
Expect Secure Communication
The UHF Military SATCOM compatibility of our amplifier ensures secure and reliable communication. This is especially crucial in military operations where secure communications can be a matter of life and death. However, this feature is not limited to military use; it also offers peace of mind in any scenario where secure communication is paramount.
The Mnemonics 200-Watt Power Amplifier is more than just a device; it’s a commitment to quality, performance, and value. With this amplifier, you can expect nothing less than excellence. Trust Mnemonics for your amplification needs and experience the difference that quality manufacturing can make.
Download the 200W HPA Datasheet
Elevate Your Communications with the 100 Watt Mobile/Airborne SATCOM HPA
Are you looking to clean up your communications without breaking the bank? When it comes to maintaining a robust and reliable communication system, nothing beats the 100-watt Mobile/Airborne SATCOM High Power Amplifier (HPA) from Mnemonics Inc. This state-of-the-art device is more than just an amplifier; it’s a game-changer in the world of wireless communication, particularly for military and airborne applications. Have peace of mind with reliable communications from this powerful amplifier. Reach out to us for more information on this amplifier, and experience the undeniable benefits of the 100 Watt Mobile/Airborne SATCOM HPA.
Download the 100W HPA Datasheet here to learn more.
Unmatched Performance
The 100-watt Mobile/Airborne SATCOM HPA is engineered with UHF Military SATCOM support, offering unparalleled performance even in the most challenging conditions. It’s designed to handle a variety of waveforms, including FM, FSK PSK CPM, TDMA/DAMA, MUOS, and WCDMA, ensuring your communication lines remain open and clear, regardless of the operational environment.
Energy Efficiency and Cost-Effectiveness
One of the standout features of this amplifier is its low power usage. In today’s eco-conscious world, energy efficiency is not just a good-to-have feature; it’s a must-have. This device delivers high efficiency without compromising on its performance, making it an excellent choice for operations that value sustainability and cost-effectiveness.
Speaking of cost-effectiveness, the 100-watt Mobile/Airborne SATCOM HPA is competitively priced, offering the lowest cost in its category without skimping on quality or functionality. This
makes it an ideal choice for budget-conscious operations that still demand top-tier performance.
Rugged and Reliable
This amplifier is built to withstand tough conditions. Its sturdy construction can handle high humidity levels, wide temperature ranges, and high altitudes. Whether you’re operating in a hot desert, a humid jungle, or high above the clouds, this device will continue to deliver exceptional performance. Its thermal shutdown feature with auto-recovery also ensures the device stays safe and functional even under extreme temperatures.
Why Choose the 100-Watt Mobile/Airborne SATCOM HPA
Choosing the 100-watt mobile/Airborne SATCOM HPA is not just a practical decision; it’s an essential one. This device offers peace of mind, knowing that your communication lines will remain robust and reliable, no matter what. It’s about feeling secure, knowing that you’re backed by a product from a reputable company like Mnemonics Inc., which has a track record of delivering high-quality, reliable products.
It’s also about feeling proud. By choosing this amplifier, you’re choosing a product that supports sustainability through energy efficiency. You’re making a statement about your values and priorities, showing that you care about the environment while still demanding top-notch performance.
The 100 Watt Mobile/Airborne SATCOM HPA is more than an amplifier. It’s a tool that enhances communication, fosters sustainability, and provides peace of mind. Its unmatched performance, energy efficiency, ruggedness, and cost-effectiveness make it a top choice over other amplifiers in the market. Choose the 100 Watt Mobile/Airborne SATCOM HPA from Mnemonics, and elevate your communication to new heights.
75-Watt Solid State Power Amplifier
Introducing the Mnemonics 75-Watt Solid State Power Amplifier (SSPA) – your wideband, highly efficient, and highly linear RF amplification solution. This amplifier delivers exceptional performance with a frequency range of 2 to 6 GHz and an instantaneous bandwidth exceeding 100 MHz.
Download the 75W Solid State Power Amplifier Data Sheet Here
Powerful Technology
The key to its high gain, power, and bandwidth lies in its utilization of Gallium Nitride (GAN) devices and 90-degree hybrid couplers. These cutting-edge components enable the SSPA to achieve unparalleled functionality.
Equipped with an onboard microcontroller, the SSPA ensures optimal performance by monitoring DC power and facilitating R-485 communications with the host radio system. The RS-485 interface and 28 DC-volt supply line are conveniently accessible through a sub-D connector.
Dual Radio Frequency (RF) Inputs
The 75-watt solid-state amplifier has two radio frequency (RF) inputs, offering numerous advantages. Using two input radios simultaneously provides redundancy and ensures uninterrupted operation in case of a failure. Additionally, the RS-485 interface allows seamless switching between inputs, granting the amplifier the flexibility to adapt swiftly to different communication needs. The output is provided through a standard TNC Type RF connector, ensuring compatibility with a wide range of devices. This dual-input feature enhances efficiency, eliminating the need for extra external equipment or switches, saving space and energy. Moreover, the ability to accommodate different frequencies on each input enhances the overall functionality of the amplifier, making it highly versatile across a wide range of applications. The inclusion of dual RF inputs significantly enhances the amplifier’s robustness, adaptability, and efficiency, optimizing its operational effectiveness.
Gallium Nitride Powered
GAN devices are known for their exceptional power density and efficiency, enabling remarkable advancements in power output while maintaining compact size and effective heat dissipation. These devices facilitate high-frequency operation, extending the amplifier’s bandwidth and enhancing signal transmission capabilities. The superior thermal characteristics of GAN devices also ensure efficient heat dissipation, a critical aspect for high-power operations, thereby contributing to the longevity and reliability of the amplifier system. Each high-power GAN device is independently biased and features independent temperature compensation to maintain gain flatness over temperature. The 75-watt SSPA incorporates RF detectors at its input and output ports, providing accurate signal level measurements. Furthermore, a high-power wideband bi-directional coupler at the output port allows for precise measurement of both reverse and forward powers.
Discover Unmatched Performance
Experience the power and versatility of the Mnemonics 75-Watt Solid State Power Amplifier. Whether you need enhanced RF amplification for communication systems, radar applications, or other wireless solutions, this amplifier delivers exceptional performance and reliability.
Enhanced Performance
The amplifier’s comprehensive band coverage, high efficiency, and high linearity contribute to improved signal quality and transmission performance. It ensures consistent and reliable amplification across the 2 to 6 GHz frequency band, making it ideal for various applications, including communication systems and radar technology.
Increased Power Output
With a power rating of 75 Watts, this SSPA delivers substantial power amplification, enabling more robust and reliable signal transmission. This increased power output can extend the range and effectiveness of wireless communication systems, allowing for better connectivity and coverage.
Flexibility and Versatility
The inclusion of two RF inputs with input selection via the RS-485 interface allows users to connect and switch between two input radios seamlessly. This versatility allows easy integration into existing radio systems without additional equipment or complex setup processes
Precise Signal Monitoring
The RF detectors at the input and output ports of the SSPA enable accurate measurement of signal levels so users can monitor and optimize the performance of their RF systems effectively. Additionally, the microcontroller within the amplifier continuously monitors DC power and facilitates communication with the host radio system, ensuring optimal operation and performance.
Reliability and Durability
The Mnemonics 75-Watt SSPA is designed with high-quality components, including Gallium Nitride (GAN) devices and 90-degree hybrid couplers. These components contribute to the amplifier’s reliability, durability, and long-term performance. The independent biasing of GAN devices with temperature compensation ensures stable gain flatness over temperature variations, further enhancing its reliability.
Features:
- In Air or On Land: Adaptable functioning across fixed-wing aircraft and ground vehicle applications
- Flexible Design: Supports frequency ranges up to 6GHz
- Compact Size: Makes for simple transport and flexible usage
- Wide Bandwidth: Supports a greater spectrum of radios
- Dual Radio Frequency (RF) Inputs
Key Specifications:
- Frequency: Covers the 2 to 6 GHz frequency band
- Operating Temperature: Can operate in extreme temperatures from -40 °C to +85 °C
- Altitude: Can be used correctly up to 65,000 feet
- Vibration: MIL-STD-810, Method 514, Procedure 1
- Shock: MIL-STD-810, Method 516, Procedure 1
- Humidity: <IL-STD, Method 507, 4 – 48-hour cycles
- EMI/EMC: MIL-STD-461F, RE102, CE102
Why Choose The 75-Watt Solid State Power Amplifier
Experience enhanced performance, increased power output, and precise signal monitoring with the Mnemonics 75-Watt Solid State Power Amplifier. This reliable and durable amplifier offers a robust power output of 75 watts, effortlessly driving a wide variety of speakers for remarkable system flexibility. By optimizing components, it minimizes power wastage while maximizing output signal strength. Rest assured that your signals will be transmitted with precision and accuracy, thanks to the dual RF input system, which adds durability and flexibility to the mix. Focus on your mission with confidence, knowing that the Mnemonics comprehensive solution ensures the reliability and performance you need.
Download the 75W Solid State Power Amplifier Data Sheet Here.
50 Watt-Solid State Power Amplifier
The Mnemonics 50-Watt Solid State Power Amplifier (SSPA) is an advanced RF amplifier that operates across the 2 to 6 GHz frequency range, providing wideband coverage with an impressive instantaneous bandwidth of over 100 MHz. This highly efficient and linear amplifier delivers reliable, long-term performance for a multitude of applications. Powered by standard 28 VDC at a maximum current of 11 Amperes, it embodies superior technology, ensuring the highest levels of accuracy and reliability.
Download the 50W Solid State Power Amplifier data sheet here
Technologically Advanced
The 50-watt SSPA achieves high gain, power, and bandwidth through multiple Gallium Nitride (GAN) devices and 90-degree hybrid couplers. It incorporates an onboard microcontroller to monitor DC power and R-485 communications with the host radio system. The RS-485 interface and 28 DC-volt supply line are connected via a sub-D connector. Additionally, the SSPA features two RF inputs (SMA connectors) that allow simultaneous use of two input radios, with input selection controlled through the RS-485 interface. The SSPA’s output is delivered through a standard TNC Type RF connector.
Each high-power GAN device is independently biased with independent temperature compensation for gain flatness over temperature. The 50-Watt SSPA has RF detectors at its input and output ports. The output port uses a high-power wideband bi-directional coupler to measure reverse and forward powers. The RF detectors feed the signal levels to the microcontroller while maintaining gain flatness over frequency and temperature.
Gallium Nitride Advantage
Incorporating Gallium Nitride (GAN) devices can significantly enhance the performance of a 50-watt solid-state amplifier. GAN devices are well-known for their exceptional power density and efficiency, allowing for a significant improvement in power output without sacrificing size or heat dissipation. Additionally, GAN devices offer high-frequency operation, extending the amplifier’s bandwidth and enhancing its signal transmission capabilities. Moreover, GAN’s superior thermal characteristics ensure effective heat dissipation, which is crucial for high-power operations, thereby contributing to the amplifier system’s longevity and reliability. In summary, GAN devices have the potential to provide a substantial performance boost to a 50-watt solid-state amplifier.
High-Gain, High-Power
A high-gain, high-power component significantly enhances the performance of a 50-watt solid-state power amplifier. It increases the gain of the amplifier, resulting in a more robust output signal. The amplifier can drive heavier loads, a crucial factor in highly demanding scenarios. Further, it can improve the amplifier’s efficiency by reducing power wastage, thereby saving energy. These components can help the amplifier provide cleaner and more consistent signal transmission, reducing the chances of communication distortion or breakdown. The high-gain, high-power component in our 50-watt solid-state power amplifier leads to higher operational efficiency and reliability.
Dual Radio Frequency (RF) Inputs
The dual radio frequency (RF) inputs in the 50-watt solid-state amplifier offer several advantages. Simultaneously using two input radios provides redundancy and ensures continuous operation even if one input fails. Additionally, the capacity to switch between inputs via the RS-485 interface brings flexibility, enabling the amplifier to adapt to varying communication needs quickly. This dual-input feature also enhances efficiency, reducing the need for additional external equipment or switches, saving space and energy. Furthermore, the possibility of different frequencies on each input can enhance the amplifier’s overall function, improving its versatility across a broader range of applications. Dual RF Inputs significantly contribute to the amplifier’s robustness, adaptability, and efficiency, augmenting its operational effectiveness.
Features
- In Air or On Land: Adaptable functioning across fixed-wing aircraft and ground vehicle applications
- Flexible Design: Supports frequency ranges up to 6GHz
- Compact Size: Makes for simple transport and flexible usage
- Wide Bandwidth: Supports a greater spectrum of radios
- Dual Radio Frequency (RF) Inputs
Key Specifications
- Frequency: Covers the 2 to 6 GHz frequency band
- Operating Temperature: Can operate in extreme temperatures from -40 °C to +85 °C
- Altitude: Can be used correctly up to 65,000 feet
- Vibration: MIL-STD-810, Method 514, Procedure 1
- Shock: MIL-STD-810, Method 516, Procedure 1
- Humidity: <IL-STD, Method 507, 4 – 48-hour cycles
- EMI/EMC: MIL-STD-461F, RE102, CE102
Why Choose The 50-Watt Solid State Power Amplifier
The 50-watt Solid State Power Amplifier is an exceptional product. It offers high-power and high-gain capabilities, ensuring reliable and robust signal transmissions. With its optimized components, it minimizes power wastage while maximizing the strength of the output signal. This comprehensive solution provides the reliability and performance you can depend on. Focus on your mission knowing that your signals will be transmitted with precision and accuracy. The dual RF input system enhances durability and flexibility, giving you added peace of mind.
Download the 50W Solid State Power Amplifier data sheet here.
20 Watt UHF Military SATCOM Amplifier
Our UHF Military SATCOM Amplifier is a highly efficient and cost-effective solution for your communication needs. Perfectly designed to support waveforms such as FM, FSK PSK, CPM, TDMA/DAMA, MUOS, and WCDMA.
Download the 20W Solid State Power Amplifier data sheet here
Versatile Product
Our UHF Military SATCOM Amplifier is a cornerstone in military communication technology, providing users with a range of benefits that greatly improve their operational efficiency and reliability. This product is designed to meet the rigorous demands of modern military operations, making it an essential tool for anyone seeking to enhance their communication capabilities.
One of the key benefits of this amplifier is its ability to support various waveforms such as FM, FSK, PSK, CPM, TDMA/DAMA, MUOS, and WCDMA. This versatility ensures compatibility with a wide range of communication systems, increasing its utility across different platforms. By being able to interface with multiple systems, users can streamline their operations, reducing the need for multiple devices and, therefore, decreasing logistical challenges and stress from trying to use multiple devices.
The compact size and relatively light weight of this amplifier make it easy to integrate into existing systems. Whether you’re operating in a vehicle, a command center, or in the field, it won’t add unnecessary bulk or weight to your setup.
Reliable Communication
The UHF Military SATCOM Amplifier operates at a frequency of 220-320 MHz, providing sufficient bandwidth for robust and reliable communication. This broad frequency range enables the transmission of large amounts of data quickly and efficiently, ensuring that critical information reaches its intended recipients without delay.
Low Power High Performance
The product’s low power usage, combined with its high efficiency, makes it an environmentally friendly choice. It consumes less power compared to other amplifiers in the market, reducing energy costs and promoting sustainability. Despite its low power consumption, it delivers a high output power of 20 Watts, maintaining strong signal strength even in challenging conditions.
This amplifier also stands out due to its impressive gain flatness over temperature and frequency. Regardless of operating conditions, it maintains a consistent performance, ensuring reliable communication at all times. This feature is particularly beneficial in fluctuating environmental conditions, where other amplifiers might struggle to maintain their performance.
Furthermore, the UHF Military SATCOM Amplifier features a no-load protection capability, meaning it can withstand up to 20 Watts with no load. This feature increases the product’s durability and lifespan, providing users with a long-lasting solution for their communication needs.
Key Features
- Frequency: The amplifier operates at a frequency of 220-320 MHz.
- Output Power (P1 dB): It has an output power of 20 Watts.
- Gain: The gain varies with temperature. At +2 degrees Celsius and at 0 degrees Celsius, it’s 44+ldB. At +25 degrees Celsius, it’s t0.5 dB.
- Gain Flatness Over Temperature and Frequency: The gain flatness over temperature and frequency is + 0.5 dB, 22Q-320 MGz.
- HPA Efficiency: The HPA efficiency of the amplifier is 50%.
- DC Power: The DC power is 28 VDC (1.5 Amps).
Additional Specifications
- Power Connector: D89
- RF ON/OFF Control: Vx.vLi “J TTL Level
- Keyline Connector: D38999\20M1 1 -35P, Conn, CIRC, RCPT, 13 PIN
- Keyline On/Off Isolation: > 80 dBc
- Harmonics/Spurious: >15d8/<-70dBc
- Input / Output Impedance: 2:1
- Input/ Output VSWR: 50 Ohms
- No Load Protection: Can withstand 20 Watts with NO LOAD
- RF In/Out Connectors: SMA
- Operating Temperature: 0 degrees C to +70 degrees C
- Size: 5.0×3.5×1.0in (LxWxH) and 12.62 x 7 .62 x 2.25 in (1/4 ATR)
- Weight: 20.0 Oz and 7.25lbs (ATR config)
- Over Temperature Alarm: Factory set @ +85 degrees C
Why Choose the 20W UHF Military SATCOM Amplifier
After using our UHF Military SATCOM Amplifier, purchasers can expect to feel confident in their communication capabilities. The reliability and efficiency of this product mean that you can trust it to perform when you need it most, allowing you to focus on other aspects of your mission. The peace of mind that comes with knowing your communications are secure and reliable is invaluable in high-stakes military operations.
The UHF Military SATCOM Amplifier is more than just a product; it’s an investment in reliable, efficient, and robust communication. Its combination of versatility, power, and durability makes it an invaluable tool for any military operation. By choosing this amplifier, you’re choosing a product that delivers exceptional performance without compromising on efficiency or sustainability. The result is clear, reliable communication, no matter what challenges you face.
